Processors | Cores & Threads | Cache | Base Frequency | Max Turbo Frequency | Graphics |
Core i9-9880H | 8 cores, 16 threads | 16M | 2.30 GHz | 4.80 GHz | Intel UHD Graphics 350MHz-1.20GHz |
Core i5-10300H | 4 cores, 8 threads | 8M | 2.50 GHz | 4.50 GHz | Intel UHD Graphics 350MHz-1.05GHz |
Core i7-10750H | 6 cores, 12 threads | 12M | 2.60 GHz | 5.00 GHz | Intel UHD Graphics 350MHz-1.15GHz |
Core i9-10880H | 8 cores, 16 threads | 16M | 2.30 GHz | 5.10 GHz | Intel UHD Graphics 350MHz-1.25GHz |
Core i9-10980HK | 8 cores, 16 threads | 16M | 2.40 GHz | 5.30 GHz | Intel UHD Graphics 350MHz-1.25GHz |
Basic Information: | |
CPU | Intel Core i9-9880H |
CPU Installation Method | FCBGA1440 |
TDP | 45W |
Level 3 Cache | 16MB |
Motherboard | 144.2 x 141.0 mm |
BIOS | American Megatrends Inc. |
Code Name | Intel Coffee Lake |
Chipset | HM370 Chipset |
Memory |
2 x SO-DIMM Slot, up to 64GB DDR4
Dual Channel, DDR4-2800MHz, DDR4-2666MHz, DDR4-2400MHz, DDR4-2133MHz
|
OS | Windows/Linux |
Audio |
Intel High Definition Audio Controller Intel Display Audio
Intel High Definition Audio Controller
|
Network |
2 x Realtek RTL8168/8111/8112 Gigabit Ethernet Controller
10/100Mbps/1000Mbps BaseT LAN
|
Video | Intel® UHD Graphics 630 |
Input/output port | |
Switch | 1 x Power On/Off Switch |
Power | 1 x 19V DC In |
LED | 1 x LED |
USB | 4 x USB3.0, 2X USB2.0 |
Type-C | 1 x Type-C3.1 |
Display | 1 x DP, 1 x HDMI |
LAN | 2 x RJ45 Giga LAN |
Audio | 1 x Audio(MIC&SPK) |
Storage | |
M.2 |
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(Only NVME PCIe3.0x4), support 6Gb/s
1 x M.2 slot for M.2 NGFF 22*80(Key M), up to 2TB(NVME/SATA), support 6Gb/s
|
SATA | 1 x SATA3.0 slot for 9.5mm SATA HDD or SSD, up to 3TB, support 6Gb/s |
Wi-Fi | |
Module | 1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G or 5G Wi-Fi B/G/N/AC or Bluetooth) |
Antenna | 2 x inner RF cables and 2 x external antennas |
Power and Working Environment | |
Input | DC100-240V AC/50-60Hz |
Output | DC +12V~+19V, recommend 19V/5A |
Operating Temperature | 0/70 Centigrade |
Storage Temperature | -20/+80 Centigrade |
Relative Humidity | 0%~90% (non-condensing) |
Product Dimension & Details | |
Size | 149.5*145.5*66.1mm |
Weight | Net 1.9kg, Gross 2.5KG |
Shell | Dark gray color aluminum alloy |
Cooling Mode | Copper Cooling Fan |
Functions | RTC, PXE |
Package Content | |
Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag |
Optional | Wi-Fi antennas, 1xHDMI cable, 1xUser Manual, 1xVESA Mount |
